Real-time

FrankenPHP ships with a built-in Mercure hub for pushing real-time events to browsers over HTTP, as a simpler alternative to WebSockets.

FrankenPHP comes with a built-in Mercure hub! Mercure allows you to push real-time events to all the connected devices: they will receive a JavaScript event instantly.

It’s a convenient alternative to WebSockets that is simple to use and is natively supported by all modern web browsers!

Enabling Mercure

Mercure support is disabled by default. Here is a minimal example of a Caddyfile enabling both FrankenPHP and the Mercure hub:

# The hostname to respond to
localhost

mercure {
    # The issuer of the access tokens, and the keys verifying them
    issuer https://localhost {
        publisher {
            jwt !ChangeThisMercureHubJWTSecretKey!
        }
        subscriber {
            jwt !ChangeThisMercureHubJWTSecretKey!
        }
    }
    # Allows anonymous subscribers (without access token)
    anonymous
}

root public/
php_server

Access tokens must carry the identifier of the issuer they were signed by in their iss claim. mercure_publish() doesn’t need any token: it publishes directly, in-process.

If you enable compression with the encode directive, exclude the hub from it: compressed SSE streams cost memory per subscriber and enable BREACH-style attacks.

@compressible not path /.well-known/mercure
encode @compressible zstd br gzip

With php-server

frankenphp php-server --mercure starts the hub without a Caddyfile, configured by environment variables:

• MERCURE_PUBLISHER_JWT_KEY and MERCURE_SUBSCRIBER_JWT_KEY (required): the keys verifying the publisher and subscriber tokens
• MERCURE_PUBLISHER_JWT_ALG and MERCURE_SUBSCRIBER_JWT_ALG (default: HS256): the algorithms these tokens are signed with
• MERCURE_TRUSTED_ISSUERS (default: https://localhost): the identifiers accepted in the iss claim of the tokens, separated by commas or spaces (the sample Caddyfile reads a single identifier from this variable)
• MERCURE_RESOURCE_IDENTIFIER (default: the URL of the hub the client contacted): the value the aud claim of the tokens must contain; set it when --domain is empty, as the site then answers any Host

The tokens must follow the format described below: the ones issued for the 0.x hub are rejected.

Subscribing to updates

By default, the Mercure hub is available on the /.well-known/mercure path of your FrankenPHP server. To subscribe to updates, use the native EventSource JavaScript class:

<!-- public/index.html -->
<!doctype html>
<title>Mercure Example</title>
<script>
  const eventSource = new EventSource("/.well-known/mercure?match=my-topic");
  eventSource.onmessage = function (event) {
    console.log("New message:", event.data);
  };
</script>

Publishing updates

Using mercure_publish()

FrankenPHP provides a convenient mercure_publish() function to publish updates to the built-in Mercure hub:

<?php
// public/publish.php

$updateID = mercure_publish('my-topic',  json_encode(['key' => 'value']));

// Write to FrankenPHP's logs
error_log("update $updateID published", 4);

The full function signature is:

/**
 * @param string|string[] $topics The first topic is the canonical one, the others are alternate topics
 */
function mercure_publish(string|array $topics, string $data = '', bool $private = false, ?string $id = null, ?string $type = null, ?int $retry = null): string {}

Subscribers matching the canonical topic or any of the alternate topics receive the update. The returned string is the ID of the update, to be used as Last-Event-ID to resume a stream.

mercure_publish() throws a ValueError when the update violates the protocol, notably when:

• a topic addresses the /.well-known/mercure namespace, which is reserved for the hub, or is *, which is reserved for the wildcard matcher;
• $id starts with #, is earliest, or contains control characters;
• $type is mercure, which is reserved for the events generated by the hub, or contains control characters;
• $data isn’t valid UTF-8;
• $retry is negative.

A TypeError is thrown when $topics is an array holding a value that isn’t a string. A RuntimeException is thrown when no hub is configured, or when the hub fails to dispatch the update.

Using file_get_contents()

To dispatch an update to connected subscribers, send an authenticated POST request to the Mercure hub with the topic and data parameters:

<?php
// public/publish.php

// An access token signed with the key of the "issuer" configured in the Caddyfile
$jwt = generate_access_token();

$updateID = file_get_contents('https://localhost/.well-known/mercure', context: stream_context_create(['http' => [
    'method'  => 'POST',
    'header'  => "Content-type: application/x-www-form-urlencoded\r\nAuthorization: Bearer " . $jwt,
    'content' => http_build_query([
        'topic' => 'my-topic',
        'data' => json_encode(['key' => 'value']),
    ]),
]]));

// Write to FrankenPHP's logs
error_log("update $updateID published", 4);

The token is an OAuth 2.0 access token, signed with the key of the issuer block of the Caddyfile. Its header must contain "typ": "at+jwt", and its payload must grant the publish action on every topic of the update:

{
  "iss": "https://localhost",
  "aud": "https://localhost/.well-known/mercure",
  "exp": 4102444800,
  "authorization_details": [
    {
      "type": "https://mercure.rocks/authorization-detail",
      "actions": ["publish"],
      "topics": [{ "match": "my-topic" }]
    }
  ]
}

iss must be the identifier of the issuer block, and aud the URL of the hub. See the Mercure documentation about authorization.

Generate these tokens dynamically, using a trusted JWT library: the protocol requires an expiration date, so they cannot be hardcoded.

Using Symfony Mercure

Alternatively, you can use the Symfony Mercure Component, a standalone PHP library.

This library handles the JWT generation, update publishing as well as cookie-based authorization for subscribers. Support for the Mercure protocol 1.0 requires symfony/mercure 0.8 or later.

First, install the library using Composer:

composer require symfony/mercure lcobucci/jwt

Then, you can use it like this:

<?php
// public/publish.php

require __DIR__ . '/../vendor/autoload.php';

const JWT_SECRET = '!ChangeThisMercureHubJWTSecretKey!'; // Must be the same as the publisher jwt in Caddyfile

// Set up the JWT token provider, issuing Mercure 1.0 access tokens
$jwFactory = new \Symfony\Component\Mercure\Jwt\LcobucciFactory(
    JWT_SECRET,
    jwtLifetime: 3600,
    protocolVersion: \Symfony\Component\Mercure\ProtocolVersion::V1,
);
$provider = new \Symfony\Component\Mercure\Jwt\FactoryTokenProvider(
    $jwFactory,
    [new \Symfony\Component\Mercure\Jwt\Grant([\Symfony\Component\Mercure\Jwt\Grant::ACTION_PUBLISH], ['*'])],
    [
        'iss' => 'https://localhost',
        'aud' => 'https://localhost/.well-known/mercure',
        // Required by RFC 9068: the subject and the client the token is issued to
        'sub' => 'https://localhost',
        'client_id' => 'https://localhost',
    ],
);

$hub = new \Symfony\Component\Mercure\Hub(
    'https://localhost/.well-known/mercure',
    $provider,
    protocolVersion: \Symfony\Component\Mercure\ProtocolVersion::V1,
);
// Serialize the update, and dispatch it to the hub, that will broadcast it to the clients
$updateID = $hub->publish(new \Symfony\Component\Mercure\Update('my-topic', json_encode(['key' => 'value'])));

// Write to FrankenPHP's logs
error_log("update $updateID published", 4);

Mercure is also natively supported by:

• Laravel
• Symfony
• API Platform
